Traversing Feeder Type
Straightener Specifications :
Model Number - CERF-60-72
Serial Number – 160-2480
Max Material Thickness - .235”
Min Material Thickness - .030”
Max Material Thickness 72” @ 1200MPA – .125”
Max Material Width – 72”
Min Material Width – 6”
Max SPM – 25SPM @ 48” of Progression
Uncoiler Specifications:
Model Number - CHDRCK-5000-72
Serial Number – 120-2479
Max Material Thickness - .235”
Min Material Thickness - .030”
Max Material Thickness 72” @ 1200MPA – .125”
Max Material Width – 72”
Min Material Width – 6”
Max SPM – 25SPM @ 48” of Progression
Max Coil Weight – 50,000lbs
Max Coil OD – 72”
Max Coil ID – 24.5”
Min Coil ID – 19.5”
Fanuc Robotic De-Stacker Specifications
Two Bin Towers
Nesting Table
One Robot to de-stack blanks from bin and placing on to nesting table.
One Robot taking blank from nesting table on to the blank conveyor.
Robots can handle 200lbs at 10SPM.
Titan Blank Conveyor
Max Weight – 200lbs
Max Width – 60”
Min Width – 24”
