Brand
Not Specified
Model
Y28-300T
Stock #
502016
Condition
Not specified
Year
2020
Location
Detroit, Michigan
United States
Nominal Force: 3000 KN (300 Tons
Maximum Slide Stroke: 1600 mm
Effective Table Dimensions: 2300 mm x 1300 mm
Rapid Approach Speed: 250 - 350 mm/s
| No. | Item | Unit | Value | Remarks |
| 1 | Nominal Force | KN | 3000 | |
| 2 | Maximum Working Pressure | Mpa | 20 | |
| 3 | Opening Force | KN | 500 | |
| 4 | Return Force | KN | 200 | |
| 5 | Maximum Slide Stroke | mm | 1600 | |
| 6 | Max. Distance from Slide Underside to Table | mm | 1800 | |
| 7 | Table Height Above Floor | mm | 760 | Incl. 30mm bolster |
| 8 | Effective Table Dimensions (L-R x F-B) | mm | 2300 x 1300 | |
| 9 | Slide Speed | |||
| - Rapid Down (Main Cylinder) | mm/s | 250-350 | ||
| - Slow Down/Pressing (Main Cylinder) | mm/s | 15-30 | ||
| - Rapid Return (Main Cylinder) | mm/s | 350 | ||
| 10 | Height Above Ground | mm | 6675 | |
| 11 | Machine Footprint (L-R x F-B) | mm | 4050 x 3000 | |
| 12 | Total Power | KW | 95.1 |
