Specifications:
Press Bed Size: 96” x 144”
Stroke Length: 12”
Shut Height: 27” Minimum
Window Opening: 83” Wide x 131” Long
Overall Height: Approx. 18’
Base to Floor Dimension: 36”
Force Capacity:
Compressive Force: 452.43 Tons @ 3000 PSI & 377.025 Tons @ 2500 PSI
Lifting Force: 231.09 Tons @ 3000 PSI &191.325 Tons @ 2500 PSI
Hydraulic System:
Flow Rate: 120 GPM @ 3000 PSI Max
Oil Type: ISO 68
Oil Capacity: 310 Gallons
Chiller Capacity: 20 Tons (2 x 10 Ton Units), 240,000 BTU/HR
Electrical:
460 VAC — 3 Phase — 60 Hz — 275 Amps
115 VAC — 1 Phase — 60 Hz — For Control Panel (Amps not specified)
Pneumatic Requirements:
None
Quantity 1
