Nominal Force (Stamping Force): 6300 kN Nominal Force (Stamping Force): 708 Short Ton Nominal Force (Stamping Force): 632 Long Ton
Die Space: (1300 mm) 51.18"
Closing Speed: (300 mm/s) 11.81" Maximum Working Speed: (24 mm/s) .945" Working Speed at Nominal Force: (47 mm/s) 1.85" Max. Die Area (BxD): (3700 x 2200 mm) 145.67" x 86.61" Min. Die Are (BxD) at Nominal Force: (1900 x 1150 mm) 74.80" x 45.27" Min. Die Height: (500 mm) 19.68" Max. Die Total Weight: (17.000 kg) 17-Ton Max. Die Upper Part Weight: (8000 kg) 17,636 Lbs
